Description
Adds two USB Type A ports & one USB Type C port (5Gbps), a 4K HDMI and DP port, Gigabit Ethernet and an Audio port to a laptop
Supports 3840×2160@30Hz for an HDMI or DP display and Full HD 1920×1080 for simultaneous use of HDMI and DP displays
Features DisplayPort Alternate Mode
Allows USB Power Delivery (PD 3.0, up to 100W) to charge the laptop while using the DST Mini XT
2 year warranty
Extended Displays. This DST-Mini XT can support a single extended display with 4k 30Hz capability through the HDMI or DisplayPort connections. Dual display setups are also possible with crisp Full HD 1080p. This makes this dock the perfect solution for any creative, data analyst or intense spreadsheet worker.
Versatile. Including the HDMI and DisplayPort connections, this docking station can unlock a world of connectivity for your device. Delivering Gigabit Ethernet, SD Card Slot, USB-C, SuperSpeed USB Type A ports and a combined 3.5mm headphone jack. To pack as much functionality into this smaller form factor, we have included a multifunctional USB Type A port. Delivering both SuperSpeed data transfer (5Gbps) and USB Battery Charging Specification 1.2 with one port, you can charge portable devices, including mobile phones.
Pass-through Charging. Thanks to the USB-C PD 3.0, by connecting a USB-C charger to the DST-Mini XT you can expect up to 100W fast charging of the connected laptop. With Battery Charging 1.2, one of USB Type A port delivers 5V and up to 1.5A for faster charging. Simply connect one USB-C cable and be confident that your laptop and connected devices will be fully charged and ready to go.
Plug and play. This docking station does not require any driver installation. This allows for seamless large-scale implementation and a hassle-free experience.
Specifications
Product ID: 43323
Interface: USB Type C to 1x HDMI / 1x DP / 1x RJ45 / 2x USB Type A / 1x USB Type C / 1x SD / 1x Audio
Interface Standard: USB 3.2 / 3.1 Gen 1 / USB 3.0, HDMI 1.4, DP 1.2, Gigabit LAN, Audio (combo)
Supported Bandwidth: 5 Gbps, 10/100/1000 Mbps
Maximum Input Resolution: 3840×2160@30Hz
Maximum Output Resolution: 3840×2160@30Hz (HDMI), 3840×2160@30Hz (DP), simultaneous connection: 1920×1080
Chipset: VL102-Q4, VMM3332, RTL8153B, VL817, FE1.1S, GL823K, HS-100B, VL163, MP28167
Compatibility: USB Type C or Thunderbolt 3/4 equipped computers with DisplayPort Alternate Mode support. Windows, macOS, Linux, Android, ChromeOS.
Power Delivery: PD 3.0 up to 100W (20V 5A)
HDCP Support: HDCP 1.4
Supported Audio: Supports 48/44.1kHz audio sampling rate
Separate Audio Ports: 1x Audio combo port 3.5mm
Special Features: DisplayPort Alternate Mode, MST Extended display support, USB Type C Female port supports power and data, 1x Battery Charging 1.2 port
Connectors
Inputs: 1 x USB Type C (Male)
Outputs: 1x HDMI (Female), 1x DisplayPort (Female), 1x RJ45 (Female), 2x USB Type A (Female), 1x USB Type C (Female) / 1x SD slot, 1x 3.5mm Audio (Female)
Power: 1 x USB Type C (Female) PD port
