Description
- 10 Ports: 10× 10/100 Mbps RJ45 ports with 8 PoE+ ports
- Two Cables in One: With 8 PoE+ ports, transfers data and power on one single cable
- High Power PoE+: Support PoE Power up to 30 W for each PoE port and 65 W for all PoE ports*
- 2× Uplink Ports: MS110P provides 2× uplink ports when turning on the isolation mode. One for connecting to the Internet and one for connecting to the NVR.
- Long-Range up to 250 m: Increases PoE transmission distance to 250 m by Extend Mode*
- Isolation Mode: One click to divide traffic for specific ports for stability and security
- Compliant with Powered Devices: Works with IEEE 802.3af/at compliant PDs
- Durable Metal Casing: Allows for efficient heat dissipation and long network life
- Plug and Play: Simple to use and saves time and effort
- PoE Auto Recovery: Automatically reboots your dropped or unresponsive PoE-powered devices
Specifications
- Product ID: MS110P
- Dimensions:171*98*27 mm
- PoE Ports
- RJ45
- Standard: Compliant with 802.3 af/at Powered Devices
- PoE Ports: Port 1- Port 8
- PoE Power Budget: 65 W
- Interfaces: 10× 10/100 Mbps Ports, Auto-Negotiation, Auto MDI/MDIX
- External Power Supply: External Power Adapter (Output: 53.5V/1.31A)
- Standards and Protocols:
- IEEE 802.3x Flow Control
- Data Rates
- 10/100 Mbps at Half Duplex
- 20/200 Mbps at Full Duplex
- Jumbo Frame: 2 KB
- Mac Address Table: 2K
- Max Power Consumption
- 10.064 BTH/h (no PD connected)
- 263.568 BTH/h(with 65W PD connected)
