Logitech Rally Bar Graphite:960-001312 / White: 960-001324
With a dual-camera system and RightSight 2 auto-framing technology, Rally Bar welcomes remote participants to the conversation. Choose Grid View to eliminate empty space and frame each person in their own stream, Speaker View to highlight the active speaker, or Group View to capture everyone in the room.
Description
An innovative dual-camera system with optical zoom and an AI Viewfinder delivers fluid, cinematic video in medium and large rooms.
Rally Bar’s advanced audio engineering delivers powerful, room-filling sound and makes sure every voice is clearly heard.
Auto-level loud and soft voices – while suppressing unwanted noise – with AI-based RightSound technology that improves over time.
Easily accommodate larger spaces with Rally Mic Pods. Out of the box, Rally Bar has a pickup range up to 7 m, which you can significantly extend by adding up to four Mic Pods.
Run supported video conferencing applications – such as Microsoft Teams® Rooms and Zoom® Rooms – directly on the device with no computer or laptop required.
Connect via USB to virtually any PC or Mac with no additional software needed.
Easily manage your Logitech video collaboration devices with Logitech Sync. Monitor room health, deploy updates, and modify settings all from a single cloud-based platform. And with Sync Insights, you can see how meeting spaces are utilized over time.
Additional information
Color | Graphite, White |
---|
Specifications
Product Id: Graphite:960-001312 / White: 960-001324
Internet Connection: Wired or wireless
USB Mode: Windows® 11, Windows 10, the two most recent versions of macOS
Certifications & Compatibility
Certifications
Microsoft Teams Rooms on Androidâ„¢ 2For medium sized rooms
Microsoft Teams Rooms on Windows 3For medium sized rooms
Zoom Roomâ„¢
Tencent Meeting Rooms
Google Meet (ChromeOS/USB)
Appliance Mode: Supports compatible video conferencing software in appliance mode (no PC required), including
Microsoft Teams Rooms on Android
Zoom Rooms
RingCentral Roomsâ„¢
Tencent Meeting Rooms
USB Mode: Plug-and-play USB connectivity with virtually any video conferencing application
For the latest information on certifications and compatibility, visit www.logitech.com/support/vc-certifications
General Specifications
Built-in Components: 6 beamforming microphones, PTZ camera, 2 speakers, AI Viewfinder, cable management & retention system, table stand, Logitech CollabOS platform
Enclosure: All-in-one enclosure with integrated table stand and patented speaker suspension system to eliminate vibration-induced camera shake and audio interference
Device Management: Logitech Sync
Displays Supported: 2 (up to 1080p)
Display Resolution: Up to 1080p
Network Protocol Support: IPv4, IPv6
Proxy Support: IP based Proxy, FQDN based Proxy, Proxy using PAC file
Camera
Resolution: 4K, 1440p, 1080p, 900p, 720p, and SD at 30fps
Pan: Motorized ±25°
Tilt: Motorized ±15°
Zoom: 15X HD zoom (5X optical and 3X digital)
Diagonal Field of View: 90°
Horizontal Field of View: 82.1°
Vertical Field of View: 52.2°
Total Room Coverage (field of view + pan and tilt): 132.1° Horizontal x 82.2° Vertical
Speakers
Drivers: 2x 70 mm
Sensitivity: 92 dB SPL @1W, 99dB SPL @8.0W, both +/-2dB at ½ meter
Rated Power: 8W
THD: 1kHz <2% at 1W
Speaker Sampling Rate: 48 kHz
Impedance: 4 Ohms
Microphones
Frequency Response: 90Hz – 16kHz
Sensitivity: >-36dBFS +/-1 dB @ 1Pa
Microphone data rate output: 48KHz
Pickup Range: Up to 7 m
Beamforming Elements: Six omnidirectional digital MEMS microphones forming five adaptive acoustic broadside beams
Audio processing: AEC (Acoustic Echo Cancellation), VAD (Voice Activity Detector)
Noise suppression: AI based de-noising algorithm
Add-on Mics: Supports up to 4 additional Rally Mic Pods and 2 Rally Mic Pod Hubs for larger conference rooms
RightSenseâ„¢ Technologies
RightLight: Renders natural skin tones for each participant
RightSight: Primary camera frames the active speaker while the AI Viewfinder captures everyone in the room
RightSound: Distinguishes speech from other sounds to auto-level voices while suppressing background noise and echo
Grid View: Detect and frame all meeting participants in order to create equitable hybrid meeting experiences. To learn more, visit logitech.com/prosupport/gridview
